mirror rusting tip - old willys photo; fact or fiction
Topic Started: Jul 16 2011, 01:53 PM (1,150 Views)
yjcanibul
Member Avatar
Member
[ *   *   *   *   *  ]
i've noticed in a number of old willys photos the mirror is turned down

was this to drain water from tube ?

my replacement tube holds water and its starting to rust little inside, tube is pinched close where it attaches to tub, probably would benefit from small hole drilled for drainage

was this same for the originals - any other reason willys turned mirror down ?

Posted Image


57 3B : big speedo / Hurricane / YF 938 SD / IAY-4012 / T90 / D18 / 5.375 final drive / open diffs / Firestone 6ply Military NDCC / 12v Delco SI alt / Kayline Top / venting windshield / tub patched / "still fixing leaks one at a time"

89 wrangler : h/duty axles + 5spd / 200+hp 4.2L / arb locked / multiport fuel inj / warn hubs+winch / 1/4 mil km / fishing+trail riding / gets me to work
Offline Profile Quote Post Goto Top

oldtime
Member Avatar
MODERATOR
[ *   *   *   *   *  ]
Interesting pic Randy,
Maybe used to see offroad obstacles underneath of the Jeep.
Currently building my final F-134 powered 3B .
Rock Crawler using factory parts from the Willys Motors era (1953-1963)

http://s4.zetaboards.com/CJ3B_Bulletin_Board/topic/30228766/1/#new
Offline Profile Quote Post Goto Top

Hooligan
Member
[ *   *   *   *   *  ]
Or to communicate with your significant other when you've strapped her underneath to find that rattle/vibration... :-)

1967 M38A1 CDN2 / F-134 / 24V / T90 / D-18 / 5.38
Offline Profile Quote Post Goto Top

Larry (TX)
Member
[ *   *   *   *   *  ]
Randy, many of the vintage trucks (even the larger ton and a half with flat beds) I've worked on over the years had similar mirror arms attached (inner and outter sliding arms with the set screw lock collar) to either the upper door hinge or in close proximity, and I recall seeing many with a drain hole on the underside near the lowest point ahead of the pinch and all appeared to be factory made holes.

I'd definitely drill one, perhaps from a 3/16" to a 13/64" or even a 1/4" in the arm you have to hopefully resolve the rust issue; you may even want to spray the inside of the tube (after drilling the hole) with some Rustoleum red oxide primer and swish it around some so as to coat the inside really good.

Similar situation with the lower windshield frame arms that didn't have drain holes drilled , huh?
Larry Steed
Pearland, Texas
'53 Willys CJ3B
'52 Willys M38
'86 Chevy M1009 CUCV (K5 4x4 Military Blazer)
M100 1/4 ton jeep trailer
M416 1/4 ton jeep trailer (2 ea.)
M101 CDN 1/4 ton jeep trailer
Offline Profile Quote Post Goto Top

jeeper50
Member Avatar
ol' skool jeeper jeff
[ *   *   *   *   *  ]
Hooligan,Jul 16 2011
06:52 PM
Or to communicate with your significant other when you've strapped her underneath to find that rattle/vibration... :-)

Nope that cant be it... the duct tape to keep the dust outta her mouth would keep her from communicating effectively.
In the land of the blind... the one eyed man is king
Texan at heart, Georgian by paycheck

'53 CJ3B, F134, 12v alternator, lockrights, Hot-Spark electronic module,11"self energizing brakes, Belleview winch, Beachwood summertop, OD color, built to honor all Veterans of this great country


Kayaks- Hobie Revo 13, Hobie Outback 12' both ready for the salt...
Offline Profile Quote Post Goto Top

williams3b54
Williams3B54
[ *   *   *   *   *  ]
Somebody did not tighten the mounting bolt on the bottom end of the mirror arm. Also many people don't need or even use mirrors to see what is about to plow into them so they never look to see where their mirror is.

I put a short strut arm from the mirror arm to the windshield frame to prevent this, so nobody would take a picture of my mirror hanging down and ask why?

I have the wife ride on the front bumper to check out noises and such, she just carries a little flag and when I can't see the flag any more I stop and back up to pick her up.
Dick W.
1954 CJ-3B
Semi-modified for trail riding in the Northwest.
See photos on CJ-3B page owners photos 1954.
1968 CJ-5/1975 231 odd fire V-6/ many other mods. ordered new from Toledo 1968.
Offline Profile Quote Post Goto Top

Hooligan
Member
[ *   *   *   *   *  ]
LOL... I like the flag... :-)
1967 M38A1 CDN2 / F-134 / 24V / T90 / D-18 / 5.38
Offline Profile Quote Post Goto Top

yjcanibul
Member Avatar
Member
[ *   *   *   *   *  ]
i am really liking some of these posts

anyone have what they think is an original mirror, does it have a weep hole ?

57 3B : big speedo / Hurricane / YF 938 SD / IAY-4012 / T90 / D18 / 5.375 final drive / open diffs / Firestone 6ply Military NDCC / 12v Delco SI alt / Kayline Top / venting windshield / tub patched / "still fixing leaks one at a time"

89 wrangler : h/duty axles + 5spd / 200+hp 4.2L / arb locked / multiport fuel inj / warn hubs+winch / 1/4 mil km / fishing+trail riding / gets me to work
Offline Profile Quote Post Goto Top

Bob_webber
Member Avatar
Member
[ *   *   *   *   *  ]
considering the blackout lamps, they may have had it turned down to hide the reflection of the mirror. or if it was a cold climate jeep it may have been turned down to keep water from freezing in it. wonder what the sticker said on the quarter?
53 3b, early cj5 frame (hurricane),2.43 ratio t case 26 tooth with 1 1/4" case (my own creation), late 60's c5 ross steering box, all range od, parts from a welder generator, and parts from about 9 different jeeps and counting. my every last penny and ounce of patients creates what we call the FrAnken B, the jeep that never was

bob, north east Ohio
Offline Profile Quote Post Goto Top

dortoh
Member Avatar
Member
[ *   *   *   *   *  ]
It is folded down and up against the body so it will not get broke during transport. We did it with other vehicles before we loaded them on planes to deploy. It is probably a M606 or CJ3B for the DOD. It has a black out light and venting windshield.
Lenard Gardiner
1964 CJ3B
1964 M416 trailer
Offline Profile Quote Post Goto Top

yjcanibul
Member Avatar
Member
[ *   *   *   *   *  ]
willys factory photo of prototype , mirror down

i am drilling a weep hole in my replacement


Posted Image
57 3B : big speedo / Hurricane / YF 938 SD / IAY-4012 / T90 / D18 / 5.375 final drive / open diffs / Firestone 6ply Military NDCC / 12v Delco SI alt / Kayline Top / venting windshield / tub patched / "still fixing leaks one at a time"

89 wrangler : h/duty axles + 5spd / 200+hp 4.2L / arb locked / multiport fuel inj / warn hubs+winch / 1/4 mil km / fishing+trail riding / gets me to work
Offline Profile Quote Post Goto Top

jyotin
Member
[ *   *   *   *   *  ]
There was a manufacturing defect in the mirror for a while and all objects appeared to be upside down. Sorta like using a magnifying glass at a distance.

So a Jeep executive decided that if the mirror was upside down to begin with that the end image would appear right side up.

Using these logic skills he went on to be a highy successful politician...

j
It's just my luck that something good is going to happen to me today.
54 - 3B - down on the farm
67 - cj6 - former state of Alabama vehicle
?? - cj5 T98a - made from spare parts - Ford tractor blue
?? - cj5 T98a - made from spare parts - Jeep green
Offline Profile Quote Post Goto Top

Lawrence
Member Avatar
Lawrence
[ *   *   *   *   *  ]
yjcanibul
This is an original mirror, does not have a weep hole in mirror or mirror bracket.

Posted Image

Posted Image

Lawrence
1955 CJ3B
Family Tradition
Decatur, AL
~~"Seen it all, done it all, can't remember most of it"~~
~~"We cannot direct the winds but we can adjust our sails"~~
http://cj3b.info/Owners/Wade.html
http://cj3b.info/Events/SEWillys2017.html
http://cj3b.info/Owners/WadeRiver.html
Offline Profile Quote Post Goto Top

yjcanibul
Member Avatar
Member
[ *   *   *   *   *  ]
thanks for posting Lawrence,

i see the issue now, org mirror was tube pressed close at both ends so
not likely water is getting in;

my replacement mirror is telescoptic to extend mirror , when it rains water
fills the lower tube

Posted Image
57 3B : big speedo / Hurricane / YF 938 SD / IAY-4012 / T90 / D18 / 5.375 final drive / open diffs / Firestone 6ply Military NDCC / 12v Delco SI alt / Kayline Top / venting windshield / tub patched / "still fixing leaks one at a time"

89 wrangler : h/duty axles + 5spd / 200+hp 4.2L / arb locked / multiport fuel inj / warn hubs+winch / 1/4 mil km / fishing+trail riding / gets me to work
Offline Profile Quote Post Goto Top

yjcanibul
Member Avatar
Member
[ *   *   *   *   *  ]
thought i would finish off this topic now that i know my mirror
isnt orginal design, rust proofed i an installed O-ring to keep rain out

Posted Image
57 3B : big speedo / Hurricane / YF 938 SD / IAY-4012 / T90 / D18 / 5.375 final drive / open diffs / Firestone 6ply Military NDCC / 12v Delco SI alt / Kayline Top / venting windshield / tub patched / "still fixing leaks one at a time"

89 wrangler : h/duty axles + 5spd / 200+hp 4.2L / arb locked / multiport fuel inj / warn hubs+winch / 1/4 mil km / fishing+trail riding / gets me to work
Offline Profile Quote Post Goto Top
