Stock clutch cylinder set-up; Looking to replace what I had
Topic Started: Dec 22 2012, 06:22 PM (750 Views)
Moncheche
Member Avatar
Member
[ *   *   *   *   *  ]
I had this set-up for my clutch. Posted Image

That cylinder is garbage, and my new brake set-up won't leave enough room for a similar location.

Was the stock cylinder frame mounted? Anyone have any pics handy?


1957 CJ3B (29,000 miles)
No engine* waiting for the right one to come along , Hanging pedals, Hydraulic clutch, Front Disc brake upgrade, two gas tanks, Saginaw steering.

Major work done in the 70's following an accident.

T90a trans
Warn OD
D44/D25
Offline Profile Quote Post Goto Top

P8106jr
Member Avatar
Member
[ *   *   *   *   *  ]
You mean you break?
Jamie Powers
1963 CJ3B
1947 Bantam Trailer
1973 CJ5
Houston TX
Offline Profile Quote Post Goto Top

Moncheche
Member Avatar
Member
[ *   *   *   *   *  ]
No.

As you see it, brake master is on the left, clutch on the right.

1957 CJ3B (29,000 miles)
No engine* waiting for the right one to come along , Hanging pedals, Hydraulic clutch, Front Disc brake upgrade, two gas tanks, Saginaw steering.

Major work done in the 70's following an accident.

T90a trans
Warn OD
D44/D25
Offline Profile Quote Post Goto Top

Moncheche
Member Avatar
Member
[ *   *   *   *   *  ]
I'm going to have to make something work. It's hanging pedals modification. hmmmmmm
1957 CJ3B (29,000 miles)
No engine* waiting for the right one to come along , Hanging pedals, Hydraulic clutch, Front Disc brake upgrade, two gas tanks, Saginaw steering.

Major work done in the 70's following an accident.

T90a trans
Warn OD
D44/D25
Offline Profile Quote Post Goto Top

div4gold
Member Avatar
Member
[ *   *   *   *   *  ]
Moncheche,Dec 22 2012
03:22 PM
I had this set-up for my clutch. Posted Image

That cylinder is garbage, and my new brake set-up won't leave enough room for a similar location.

Was the stock cylinder frame mounted? Anyone have any pics handy?

The stock MS was mounted on the frame about a foot or so back from the steering gear box. There should be some bolt holes there . If you look down through the round cover plate in the floor board on the drivers side you should be able to see where it was mounted, the cover plate was there to be able to check the brake fluid in the MS.
Old retired fart living in Ione, WA. I have a 1964 CJ3B. Recently overhauled original motor, transmission and overdrive. 11" Bronco drum brakes on all 4. Needs a new coat of paint but that will have to wait till next summer, it's next summer and I'm working on that now :) UPS & FEDEX will continue to profit :)
Offline Profile Quote Post Goto Top

Moncheche
Member Avatar
Member
[ *   *   *   *   *  ]
Thanks gold,

I'm going to mount the new brake master to the firewall where the 'old' one was.

The new brake master setup won't leave quite enough remove for the hydraulic clutch master.

I have just run across wilwood.com and their master cylinders. They have pretty small units that might fit the bill for my clutch set-up.

Decisions....
:wacko:
1957 CJ3B (29,000 miles)
No engine* waiting for the right one to come along , Hanging pedals, Hydraulic clutch, Front Disc brake upgrade, two gas tanks, Saginaw steering.

Major work done in the 70's following an accident.

T90a trans
Warn OD
D44/D25
Offline Profile Quote Post Goto Top

Moncheche
Member Avatar
Member
[ *   *   *   *   *  ]
Sorry, this post should have been called other than stock.....
1957 CJ3B (29,000 miles)
No engine* waiting for the right one to come along , Hanging pedals, Hydraulic clutch, Front Disc brake upgrade, two gas tanks, Saginaw steering.

Major work done in the 70's following an accident.

T90a trans
Warn OD
D44/D25
Offline Profile Quote Post Goto Top

oldtime
Member Avatar
MODERATOR
[ *   *   *   *   *  ]
Moncheche.
Please update your signature indicating some of the major modifications to your Jeep so we can provide better advice.
I believe you have a 307 Chevy with an 11" hydralic controlled clutch ?
Currently building my final F-134 powered 3B .
Rock Crawler using factory parts from the Willys Motors era (1953-1963)

http://s4.zetaboards.com/CJ3B_Bulletin_Board/topic/30228766/1/#new
Offline Profile Quote Post Goto Top
