Willys Canvas Top Rod Length
Topic Started: Sep 1 2013, 09:52 PM (991 Views)
Dom
Member
[ *   *   *   *   *  ]
G'day all,

Am hoping one of the friendly folk on the 3B Forum can help me out once more with a measurement on the original Willys canvas top hardware....

When I purchased my 3B, it came with all the main bows for an original canvas top, plus the front-bow-to-windscreen rods. It was missing the door latch rods and the front-bow-to-rear-bow rods.

I've found some suitable 3/8" rod stock and am 'starting long and trimming back' for the front-bow-to-rear-bow rods but don't want to cut too short.

Could someone please advise the end-to-end length of these? They are the plain straight rods that fit into the holes in the bows just above side window height, and they set the correct space between the front and rear bow assemblies..

I still need to figure out the door rods but I figure if I get the rest right I can just shape these to fit.

Thanks in advance, regards

Dom
Melbourne, Australia
1942 Willys MB
1945 Ford GPW
1958 Willys CJ3B
1984 Jeep CJ7
1985 Jeep CJ8 World Cab
Offline Profile Quote Post Goto Top

Lawrence
Member Avatar
Lawrence
[ *   *   *   *   *  ]
Dom
Note arrows, are these the rods you need measurements from?

Lawrence

Posted Image
1955 CJ3B
Family Tradition
Decatur, AL
~~"Seen it all, done it all, can't remember most of it"~~
~~"We cannot direct the winds but we can adjust our sails"~~
http://cj3b.info/Owners/Wade.html
http://cj3b.info/Events/SEWillys2017.html
http://cj3b.info/Owners/WadeRiver.html
Offline Profile Quote Post Goto Top

Dom
Member
[ *   *   *   *   *  ]
Hi Lawrence,

I was hoping you'd spot my plea for help! Yes please, those are the two. The PO misplaced them I think when the old top rotted away.

Thanks very much, regards

Dom
Melbourne, Australia
1942 Willys MB
1945 Ford GPW
1958 Willys CJ3B
1984 Jeep CJ7
1985 Jeep CJ8 World Cab
Offline Profile Quote Post Goto Top

jeeper50
Member Avatar
ol' skool jeeper jeff
[ *   *   *   *   *  ]
Lawrence is the man, he sent me several pics of the horizontal rods above the doors and was able to easily copy his measurements and pictures to fabricate my set of door rods.

Now we can have a set of verticle door rods too!!

We just need to get Derek to keep them in the tech section for all to use.
In the land of the blind... the one eyed man is king
Texan at heart, Georgian by paycheck

'53 CJ3B, F134, 12v alternator, lockrights, Hot-Spark electronic module,11"self energizing brakes, Belleview winch, Beachwood summertop, OD color, built to honor all Veterans of this great country


Kayaks- Hobie Revo 13, Hobie Outback 12' both ready for the salt...
Offline Profile Quote Post Goto Top

Lawrence
Member Avatar
Lawrence
[ *   *   *   *   *  ]
horizontal rods
Posted Image
Posted Image
Posted Image
Posted Image
Posted Image
1955 CJ3B
Family Tradition
Decatur, AL
~~"Seen it all, done it all, can't remember most of it"~~
~~"We cannot direct the winds but we can adjust our sails"~~
http://cj3b.info/Owners/Wade.html
http://cj3b.info/Events/SEWillys2017.html
http://cj3b.info/Owners/WadeRiver.html
Offline Profile Quote Post Goto Top

Lawrence
Member Avatar
Lawrence
[ *   *   *   *   *  ]
Verticle Door Rods
Posted Image
Posted Image
Posted Image
Posted Image

1955 CJ3B
Family Tradition
Decatur, AL
~~"Seen it all, done it all, can't remember most of it"~~
~~"We cannot direct the winds but we can adjust our sails"~~
http://cj3b.info/Owners/Wade.html
http://cj3b.info/Events/SEWillys2017.html
http://cj3b.info/Owners/WadeRiver.html
Offline Profile Quote Post Goto Top

Dom
Member
[ *   *   *   *   *  ]
Thanks very much Lawrence!

I agree these should go in the Tech section - the bows and rods are often sought after.

Regards

Dom
Melbourne, Australia
1942 Willys MB
1945 Ford GPW
1958 Willys CJ3B
1984 Jeep CJ7
1985 Jeep CJ8 World Cab
Offline Profile Quote Post Goto Top
