Horn and regulator; Correct horn and regulator for1964 dj3a
Topic Started: Jan 11 2016, 09:37 PM (748 Views)
dcwheels
Member
[ *   *   *   *   *  ]
Hello dear friends,
Taking the1964 dj to be a12 v set up from the factory what would be the correct horn and regulator for the dj.
Experts on the forum could kindly guide on the same.
Thanks.
Dinesh

Offline Profile Quote Post Goto Top

oldtime
Member Avatar
MODERATOR
[ *   *   *   *   *  ]
I have no hands on experience with DJ's but would expect that the 1964 could have had either a generator or an alternator system.
The front engine plate will indicate which type charging system was original to the particular engine that you have.
The 1964 12 volt generator system would be an Autolite MDU 7004 mated to a 923130 or a 923129 (low cut in) regulator.
A 1964 Motorola alternator system would require a # 923320 regulator.

The 1964 12 volt horn would be an Autolite with spade type terminals (# 926595).

I expect that 6 volt systems could still have been an option in 1964.
Currently building my final F-134 powered 3B .
Rock Crawler using factory parts from the Willys Motors era (1953-1963)

http://s4.zetaboards.com/CJ3B_Bulletin_Board/topic/30228766/1/#new
Offline Profile Quote Post Goto Top

dcwheels
Member
[ *   *   *   *   *  ]
Thanks a lot for that info oldtime.
I shall get some pictures this week and post those here so that the right thing can be suggested.Then I think I should start searching for the generator/alternator.
regards
dinesh
Offline Profile Quote Post Goto Top

oldtime
Member Avatar
MODERATOR
[ *   *   *   *   *  ]
I take it then that your engine has no generator nor alternator at present.
Does the lower right side of engine block have a generator bracket attached via 2 bolts ?
Or you can upload a pic of the right front engine support to show the mounting pattern of the original charge system.
Currently building my final F-134 powered 3B .
Rock Crawler using factory parts from the Willys Motors era (1953-1963)

http://s4.zetaboards.com/CJ3B_Bulletin_Board/topic/30228766/1/#new
Offline Profile Quote Post Goto Top

dcwheels
Member
[ *   *   *   *   *  ]
I shall get those pictures shortly.
The engine had an alternator,but that I thought would have been a replacement.I never knew until you revealed that these jeeps had an alternator set up too.
Offline Profile Quote Post Goto Top

dcwheels
Member
[ *   *   *   *   *  ]
oldtime can I get a picture of the autolite 12 v horn you mentioned.
thanks.
Offline Profile Quote Post Goto Top

dcwheels
Member
[ *   *   *   *   *  ]
Hello friends,
Having no experience with the Motorola alternator and the12v horn on the dj.
Can somebody on the forum help with pictures of the same.
Thanks.
Dinesh
Offline Profile Quote Post Goto Top

PapaC
Papac
[ *   *   *   *   *  ]
Quote:

Hi Charles, Found two Motorola alternator s, and I'm not sure if these are right for the dj3a. Could you help identifying which is right for the dj.also could.you help post these pics on the alternator post on the forum. Thanks and waiting to hear from you. Regards Dinesh



Dinesh. Also having no experience with DJ3A alternators this is far beyond my expertise level but here are the pictures you sent and posted as per your request.


Posted Image

Not sure how much help but here's some images of the horn that came on my rusty 1962 DJ3A convertible.

Posted Image

Posted Image
Charles Tate....North Mississippi

1956 WILLYS DJ3A Convertible
Doing ground up nuts and bolt restoration by almost entirely reconditioning original used or a few NOS DJ3A parts.

1962 WILLYS DJ3A Convertible. (For research and parts only)
Offline Profile Quote Post Goto Top

dcwheels
Member
[ *   *   *   *   *  ]
Thanks Charles for the help posting the pics. Could you please post a picture of the mounting plate on the horn.thanks
Offline Profile Quote Post Goto Top

PapaC
Papac
[ *   *   *   *   *  ]
Try this site for manuals and parts

http://www.jeepsurreygala.com/?page_id=1137



Horn like the one on my 1962

http://www.jeepsurreygala.com/wp-content/u...06/horn-but.jpg

Charles



Charles Tate....North Mississippi

1956 WILLYS DJ3A Convertible
Doing ground up nuts and bolt restoration by almost entirely reconditioning original used or a few NOS DJ3A parts.

1962 WILLYS DJ3A Convertible. (For research and parts only)
Offline Profile Quote Post Goto Top
